PRODUCT CODE: 2043

Heated forceps | Thermoclip - 2043

Heated forceps | Thermoclip: features

The THERMOCLIP heated tweezers are a useful aid during the phase of inclusion of the histological pieces.

THERMOCLIP incorporate safe, low voltage, energy-controlled heating elements which constantly maintain the tips at an optimum temperature of 60 ± 2 °C, at room temperature (~25°C), avoiding to use other heating systems.

Continuous temperature checking is ensured by LED lights.

The Thermoclip system includes:

Dual control unit

Power supply connection for two forceps

Input voltage:	230V~ 50/60 Hz
Electric power:	12W
Supply connector:	2,5 mm co-axial power socket
Forceps connectors:	3,5 mm mono jack socket
Operating temperature:	60 ± 2° C at room temperature (~25°C)
Case material:	Flame retardant ABS plastic
Dimension:	155 x 135 x 65 mm (L x D x H)
Weight:	450 g

Heated forceps red tips 1 mm

Coated with insulation and heat resistant material

Forceps material	stainless steel with polyolefin covered finger grip
Heating elements material	ceramic encased in epoxy resin
Resistance	13 Ohm at 25 °C
Nominal supply voltage	12 V AC
Tip temperature	60 ± 2 °C at room temperature (~25°C)
Nominal absorbed power	2,5 W
Connector	jack 3,5 mm
Weight	55 g

Power supply

Input	230V~ 50/60 Hz
Output	12 V =/1,4 A
Insulating class	F
Protection classification	IP 40
Class	II
Power cord length	145 cm

Additional and replacement accessories

heated tweezers
heated pestles

Cod.	Description	Quantity
4057	Spare part: red tweezers 1 mm.	1 pcs
4058	Spare part: yellow tweezers 2 mm.	1 pcs
4059	Spare part: blue tweezers 4 mm.	1 pcs
5197	Red heated pestle 8x8 mm.	1 pcs
5198	Yellow heated pestle 16x16 mm.	1 pcs
5199	Blue heated pestle 28x25 mm.	1 pcs
